| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Functions | shoeing, drilling, drilling with impact, chisel positioning |
| Toolholder type | SDS-Plus |
| Power | 900 W |
| Rotations | 0-1250 min⁻¹ |
| Hammering energy | 3.2 J |
| Impact frequency | 0-5500 min⁻¹ |
| Voltage | 220-240 V a.c. |
| Frequency | 50 Hz |
| Max. hole diameter in concrete with twist drill | 26 mm |
| Max. hole diameter in concrete with core bit | 82 mm |
| Stroke | yes |
| Rotation switch | yes |
| Electronic rotation adjustment | yes |
| Tool positioning in chuck | yes |
| Wire length | 3 m |
| Electric insulation class | II |
| Protection grade | IPX0 |
| Acoustic pressure | 95.7 ± 3.0 dB(A) |
| Acoustic power | 103.7 ± 3.0 dB(A) |
| Vibrations | 16.064 ± 1.5 / 11.366 ± 1.5 m/s² |
| Weight | 3.1 kg |
| Set includes | młotowiertarka, rękojeść dodatkowa, ogranicznik głębokości wiercenia, wiertła x3, przecinak, przebijak |
| Application | wiercenie w betonie, kamieniu i materiałach ceramicznych, lekkie prace przy skuwaniu (np. usuwanie tynków, płytek), wiercenie bez udaru w drewnie, metalu i tworzywach |
| Symbol | YT-821210 |
The SDS Plus YT-821210 rotary hammer is a versatile power tool designed for drilling with impact and chiseling in hard building materials such as concrete, stone, or brick. Thanks to the efficient impact mechanism with an energy of 3.2 J, the device ensures effective force transfer to the material, resulting in quick and efficient hole-making and demolition work.
The SDS Plus chuck allows for quick and tool-free accessory changes, while the adjustable rotational speed and the option to disable the impact significantly expand the range of applications. The tool is effective not only for working in concrete but also for drilling in wood, metal, or plastics, as well as for light assembly tasks.
Key features and specifications:
- power 900 W – efficient operation under load
- impact energy 3.2 J – effective drilling and chiseling
- rotational speed 0-1250 RPM – smooth adjustment
- impact frequency 0–5500 BPM
- max. drilling diameter in concrete: 26 mm (with a spiral drill)
- chuck SDS Plus – quick tool change
- cable length 3 m – greater freedom of movement
- noise level: 104 dB
Functionality:
- operating modes: drilling / impact drilling / chiseling
- option to disable impact – for working with soft materials
- smooth speed adjustment – better control
- rotation direction switch – screwing and unscrewing
- switch lock – comfort during prolonged use
- additional handle – stable tool guidance
- depth limiter – repeatable drilling
Applications and intended use:
- drilling in concrete, stone, and ceramic materials
- light work in chiseling (e.g., removing plaster, tiles)
- drilling without impact in wood, metal, and plastics
- assembly and installation work
Package contents:
- SDS Plus rotary hammer
- additional handle
- drilling depth limiter
- chisel and hammer
