| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRG |
| Symbol | YT-85830 |
YATO YT-85830 Tractor is a compact agricultural machine designed for precise maintenance, farming, transportation, and tasks performed in confined spaces. Its small dimensions, adjustable width, and tight turning radius contribute to high maneuverability in orchards, gardens, greenhouses, vineyards, and cultivated fields. The design, based on simple and durable technical solutions, ensures reliability in daily operation, while the 4x4 drive allows for stable performance even on uneven and challenging terrain.
The heart of the model is a 3-cylinder diesel engine XY377-C with a power output of 25 HP, meeting EURO V emission standards, which translates to efficient and economical operation. The gearbox features 6 forward gears and 2 reverse gears, combined with a two-speed PTO shaft, allowing precise adjustment of work parameters to the type of task being performed – from soil cultivation to transportation. The stable construction, appropriate ground clearance, and the ability to adjust the wheel spacing increase the machine's functionality, while safety systems, including ROPS and an operator presence sensor, enhance comfort and control during use.
The model has T2 road homologation, allowing for its legal use on public roads in accordance with applicable regulations.
Engine:
- type: XY377-C, diesel, 3-cylinder
- rated power: 18.5 kW (25 HP)
- engine capacity: 1132 cm3
- rated speed: 3000 rpm
- exhaust emission: EURO V (compliance with EU Regulation 2016/1628)
- engine weight: 99 kg
Drive System and Gearbox:
- drive: 4x4 (front and rear axle driven)
- gearbox: 6 forward gears / 2 reverse gears
- differential: 2 bevel gears with differential lock
- clutch: dry, single-plate
- brakes: wet, disc
- PTO shaft: 2 speeds, clockwise rotation: 635/1116 rpm
Dimensions and Weights:
- overall length: approx. 2500 mm
- overall width: 970-1200 mm (adjustable)
- height: 1807 mm
- wheelbase: 1270 mm
- ground clearance: 285 mm
- own weight: 620 kg (without weights), 668 kg (with weights)
- maximum permissible weight: 819-834 kg
Wheels and Chassis:
- front tires: 5.00-12 (tube-type)
- rear tires: 8.00-16 (tubeless)
- wheel spacing:
- front: 750 mm (standard), 960-1200 mm (adjustable)
- rear: 760 mm (standard), 960-1200 mm (adjustable)
- turning radius: 1700 mm (inner) / 2300 mm (outer)
Driving Speeds:
- low range:
- 1st gear: 0.74 km/h
- 2nd gear: 1.51 km/h
- 3rd gear: 2.65 km/h
- reverse: 1.48 km/h
- high range:
- 1st gear: 4.17 km/h
- 2nd gear: 8.53 km/h
- 3rd gear: 15 km/h
- reverse: 8.35 km/h
Additional Equipment:
- rear hitch and the ability to connect agricultural machines
- PTO shaft with two speeds
- ability to adjust the driving track for different field conditions
- adjustable seat position
- driver presence sensor
YT-85830 is a versatile, compact agricultural tractor with a solid construction and very good operational parameters. Thanks to its 4x4 drive, adjustable geometry, and T2 homologation, it is suitable for both fieldwork and transportation.
