| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRH |
| Type of | Skid steer |
| Rodzaj podwozia | gąsienicowe |
| Power | 18.2 kW |
| Engine (motor) capacity | 1123 cm³ |
| Rotations | 3000 min⁻¹ |
| Max. lifting capacity | 928 (50% udźwigu granicznego) kg |
| maximum load | 650 kg |
| Max. speed | 6 km/h |
| Max. reversing speed | 6 km/h |
| Dimensions | 2976x915x1466 mm |
| Długość bez osprzętu | 2272 mm |
| Maks. wysokość robocza | 3026 mm |
| Objętość łyżki | 0.14 m³ |
| Szerokość gąsienic | 230 mm |
| Liczba rolek jezdnych | 5 na każdą stronę |
| Rozstaw osi | 1073 mm |
| Cylinder diameter | 78 mm |
| Wysokość sworznia łyżki (PIN) | 2212 mm |
| Fuel type | diesel |
| Fuel tank capacity | 28 l |
| Fuel consumption | 6.1 l/h |
| Oil tank capacity | 4 l |
| Pojemność zbiornika oleju hydraulicznego | 32 l |
| Boot type | electric |
| Drive type | hydrauliczny |
| Control type | w pełni hydrauliczne joysticki |
| Engine (motor) type | Kubota D1105 |
| Cylinders number in engine (motor) | 3 |
| Piston stroke | 78.4 mm |
| Cooling | cieczą |
| Czas podnoszenia ramienia | 3.69 s |
| Czas opuszczania | 2.79 s |
| Czas przechyłu łyżki | 1.62 s |
| Kąt wysypu łyżki | 45 ˚ |
| Maks. wysokość wysypu | 1522 mm |
| Promień skrętu przodu | 1750 mm |
| Zdolność pokonywania wzniesień | 15 ˚ |
| Clearance | 213 mm |
| Ciśnienie podłoża | 0.272 / 3.95 bar/PSI |
| Working temperature range | -10 ~ +40 ˚C |
| Acoustic pressure | 72.09 ± 3.0 dB(A) |
| Acoustic power | 99.6 ± 3.0 dB(A) |
| Vibrations | 2.5 / 0.5 m/s² |
| Weight | 1510 kg |
| Set includes | minikoparka, łyżka standardowa o szerokości 915 mm |
| Application | roboty budowlane i remontowe, prace ziemne i załadunkowe, ogrodnictwo oraz architektura krajobrazu, usługi komunalne i utrzymanie terenów, gospodarstwa rolne i hodowlane, |
| Application contd | praca na podłożach miękkich, błotnistych i nierównych, prace w wąskich i trudno dostępnych przestrzeniach |
| Compatible with | YT-86420, YT-86421, YT-86422, YT-86423, YT-86424, YT-86425, YT-86426, YT-86427, YT-86428, YT-86429, YT-86430, YT-86431, YT-86432, YT-86433, YT-86434, YT-86435, YT-86436, YT-86437, YT-86438, YT-86439, YT-86440, |
| Compatible with(s) cont. | YT-86441, YT-86442, YT-86443, YT-86444, YT-86445, YT-86446, YT-86447, YT-86448, YT-86449, YT-86450, YT-86451, YT-86452 |
| Symbol | YT-86400 |
Mini tracked loader YATO YT-86400 is a compact machine of the Skid steer class, designed for intensive, multi-purpose use in construction, earthworks, municipal services, and land management. The design is based on a proven Kubota D1105 engine, which, combined with a hydrostatic tracked drive and an efficient hydraulic system, ensures stable operation, high working efficiency, and significant lifting power while maintaining compact dimensions.
The robust tracked undercarriage guarantees good traction and even weight distribution on the ground, allowing for effective work on soft, uneven, or sensitive terrain, where traditional wheeled loaders have limited mobility. The Skid steer design, equipped with precise hydraulic joystick controls, enables excellent maneuverability and efficient operation in narrow workspaces, while providing fast work cycles and high reliability in demanding operating conditions.
Key construction features:
- compact mini tracked loader of the Skid steer type designed for multi-purpose work
- high stability and lifting capacity with small machine dimensions
- fully hydraulic control via ergonomic joysticks
- hydrostatic drive ensuring smooth maneuvering and precise control
- rubber tracks with low ground pressure – stability on soft and uneven terrain
- very fast work cycles increasing work efficiency
- design adapted for year-round operation
- ability to work with a wide range of attachments (33 tools)
- standard equipment: standard bucket with a width of 915 mm
Power unit:
- engine manufacturer: Kubota
- model: D1105
- type: diesel, 3-cylinder, liquid-cooled
- maximum power: 18.2 kW (24.7 HP)
- displacement: 1123 cm³
- starting: electric
- fuel consumption: approx. 6.1 l/h
- fuel tank capacity: 28 l
- engine oil capacity: 4 l
Hydraulic system:
- control: fully hydraulic joysticks
- hydraulic pumps: Bondioli & Pavesi (Italy)
- pump types:
- double axial piston pumps in a closed circuit (drive)
- double gear pump (attachments)
- control valves: Hydro (EBI) Control (Italy)
- maximum system pressure: 27.5 MPa
- hydraulic tank capacity: 32 l
- hydraulic hoses: Letone
- hydraulic cylinders: Juxing
Drive system and undercarriage:
- main drive: fully hydraulic
- drive motors: Impro
- transmission: direct drive from hydraulic motor to gear
- undercarriage: tracked
- tracks: rubber
- track width: 230 mm
- number of rollers: 5 on each side
- working pressure of the drive system: 24.9 MPa
Working parameters:
- nominal load capacity (35%): 650 kg
- maximum lifting capacity (50%): 928 kg
- machine weight (without attachments): 1510 kg
- bucket volume: 0.14 m³
- travel speed: 6 km/h
- arm lifting time: 3.69 s
- lowering time: 2.79 s
- bucket tilt time: 1.62 s
- gradeability: 15°
Dimensions and working geometry:
- overall dimensions (L x W x H): 2976 x 915 x 1466 mm
- length without attachments: 2272 mm
- length with bucket: 2976 mm
- maximum working height: 3026 mm
- bucket pin height (PIN): 2212 mm
- dump height: 1522 mm
- bucket dump angle: 45°
- ground clearance: 213 mm
- wheelbase: 1073 mm
- front turning radius: 1750 mm
Attachments and configuration options:
The mini loader supports 33 types of working tools, including:
- buckets: standard, toothed, light, skeletal, long, 4-in-1
- forks: pallet, grass, 3-in-1
- grapples for wood and bulk materials
- augers and drills
- broom and snow plow
- subsoilers, scarifiers, and stump grinders
- hydraulic hammer
- excavators and chain excavators
- concrete mixer, mini roller, mower
- lifting hook
Purpose and applications:
- construction and renovation work
- earthworks and loading operations
- gardening and landscape architecture
- municipal services and land maintenance
- farms and breeding operations
- work on soft, muddy, and uneven surfaces
- work in narrow and hard-to-reach spaces
More photos and information can be found here.
Usage warnings:
Fire and smoking are prohibited.
Use diesel.
Vehicle frequently reversing.
